Description
The Damocles2 MINI is a compact I/O controller designed for remote monitoring and automation. It features 4 digital inputs with S0 pulse counters, allowing connection to water, gas, electricity meters, or security sensors. It also provides 2 relay outputs for remote control of devices.
Configuration is handled via a built-in web server, and the device supports secure M2M protocols (HTTPs, SNMPv3, Modbus/TCP, MQTT, and IPv6) for seamless integration with SCADA, IoT, and cloud systems. Events such as input state changes can trigger email alerts, SNMP Traps, or relay activation on another Damocles2 or Poseidon2 device.
Damocles2 MINI integrates with SensDesk Technology-based portals, enabling remote control, logging, and alarm management via email, SMS (via SMS-GW), and SNMP traps.
Features
- 4 dry contact digital inputs with S0 pulse counters
- 2 relay outputs for remote device control
- 8 virtual digital outputs for remote activation
- Built-in web interface for easy configuration
- SNMP v3, MQTT, Modbus/TCP, and HTTPS support
- Compatible with SensDesk portal for alerts and logging
- Data logging for up to 250,000 records
- PoE support (optional)
Specifications
| Feature | Description |
|---|---|
| Digital Inputs | 4 dry contact inputs with S0 pulse counters |
| Relay Outputs | 2 relays (120V AC / 60V DC, 1000mA) |
| Virtual Outputs | 8 virtual outputs (remote-controlled) |
| Network Connectivity | Ethernet (10/100 Mbit), SNMP, Modbus/TCP, MQTT |
| Alerting Methods | Email, SNMP Traps, SMS (via SMS-GW) |
| Logging Capacity | 250,000 records |
| Power Supply | 9-30V DC (optional PoE) |
| Operating Temperature | -30°C to 80°C |
| Storage Temperature | -30°C to 60°C |
| Humidity Range | 5% to 95% RH |
| Dimensions | 105 × 94 × 33 mm |
| Housing & Protection | Metal, IP40 |
Applications and Usage
- Remote equipment monitoring
- Energy consumption metering (water, gas, electricity)
- Smart building automation
- UPS and power monitoring
- Security and alarm systems
