Description
Poseidon2 4002 is a high-capacity remote monitoring and control device designed for IT infrastructure, industrial automation, and smart buildings. It supports up to 40 sensors, 12 digital inputs, 4 relay outputs, and 8 virtual digital outputs for remote relay control. It provides advanced data logging, remote alerting, and seamless integration with IoT and SCADA systems through secure M2M communication protocols, including HTTPS, SNMPv3, MQTT, and Modbus/TCP.
Key Features
- Supports up to 40 sensors (16 via 1-Wire UNI/1-Wire and 24 via RS-485)
- 12 digital inputs with 32-bit pulse counters
- 4 relay outputs (NO/NC, 120V AC/60V DC, 1000mA)
- 8 virtual digital outputs for remote relay activation
- Data logger capable of storing over 250,000 records
- Secure communication via HTTPS, SNMPv3, IPv6, MQTT, and Modbus/TCP
- IoT integration with Microsoft Azure, IBM Bluemix, and other cloud services
- Web-based configuration for easy setup and remote access
- Multiple alerting methods: email, SNMP Trap, SMS (via external gateway)
- Flexible installation: Rack, DIN rail, table, or wall mount
Technical Specifications
Specification | Details |
|---|---|
| Sensors | Up to 40 (16 via 1-Wire UNI / 1-Wire, 24 via RS-485) |
| Digital Inputs | 12 dry contact inputs with pulse counters |
| Relay Outputs | 4 relays (NO/NC, 120V AC/60V DC, 1000mA) |
| Virtual Digital Outputs | 8 remote relay control outputs |
| Network Connectivity | Ethernet 10/100Mbit, IPv6 support |
| Communication Protocols | HTTPS, SNMPv3, MQTT, Modbus/TCP, HWg-Push |
| Data Logging | Stores up to 250,000 records |
| Alert Methods | Email, SMS, SNMP Trap, remote relay activation |
| Power Supply | 9-30V DC, PoE (optional) |
| Power Consumption | 250mA |
| Operating Temperature | -30°C to +80°C |
| Humidity Range | 0% to 95% RH |
| Dimensions | 218 x 104 x 38 mm |
| Weight | 710g |
| Mounting Options | Rack, DIN rail, table, wall mount |
| Housing | Metal enclosure |
| Warranty | 60 months |
Applications and Use Cases
- Server Room and Data Center Monitoring: Tracks temperature, humidity, power supply status, and security sensors
- Industrial Process Monitoring: Monitors machinery, HVAC systems, and environmental conditions
- Cold Storage and Pharmaceutical Compliance: Ensures regulatory conditions for food and medical storage
- Smart Buildings: Automates climate control, access monitoring, and power management
- Remote Infrastructure Monitoring: Detects water leaks, fire hazards, and unauthorized access
- Surveillance System Integration: Works with security alarms, motion sensors, and access control systems
Why Choose Poseidon2 4002?
- Large sensor capacity: Supports up to 40 sensors for extensive monitoring
- Secure communication: Uses HTTPS, SNMPv3, and MQTT for encrypted data transfer
- Automated alerts: Sends notifications via email, SMS, or SNMP Traps
- Flexible deployment: Suitable for rack, DIN rail, wall, or table mounting
- IoT and SCADA ready: Integrates with cloud platforms and industrial monitoring software
Poseidon2 4002 is an advanced environmental monitoring solution designed for IT, industrial, and smart building applications, providing reliable remote access, automated alerts, and extensive sensor connectivity.
