Description
The Temp HomeBox is a small, lightweight temperature sensor housed in an elegant 40 × 40 mm plastic box. It can be mounted on a wall, ceiling, or desk using a double-sided adhesive tape. A detachable 3-meter RJ11 cableallows for easy integration with Poseidon, Ares, and HWg-STE monitoring devices.
Features
- RJ11 (1-Wire) Interface – Compatible with all HW group devices
- Compact & Lightweight – Small 40 × 40 mm design for easy installation
- Wall, Ceiling, or Desk Mountable – Can be attached using double-sided tape
- 3m RJ11 Cable Included – Supports a 1-Wire bus length of up to 60m
- Power Supply: 5V (RJ11) – Low power consumption (5mA)
Technical Specifications
Specification | Details |
|---|---|
| Detection Type | Temperature |
| Temperature Range | -30°C to +70°C |
| Accuracy | ±0.8°C (0°C to 60°C) / ±1.0°C (-10°C to 70°C) / ±2.0°C (-30°C to 80°C) |
| Resolution | 0.1°C |
| Power Supply | 5V via RJ11 (1-Wire UNI) |
| Power Consumption | 5mA |
| Cable Length | 3m |
| Galvanic Isolation | No |
| Number of Values Provided | 1 |
| Operating Environment | -30°C to 70°C / 0%RH – 100%RH |
| Storage Environment | -50°C to 70°C / 0%RH – 100%RH |
| Dimensions | 40 × 40 × 20 mm / 15g |
| Protection Rating | IP30 |
| Installation Options | Wall, Ceiling, Desk |
| Connector Type | RJ11 |
| Warranty | 24 months |
Applications & Usage
- Home & Office Temperature Monitoring – Ensures optimal comfort & energy efficiency
- Industrial & Commercial Buildings – Supports HVAC system monitoring
- Smart Building Management – Provides accurate temperature readings for automation
- Educational & Healthcare Facilities – Helps maintain temperature control in critical environments
Installation & Use
- Plug & Play – Simply connect the included 3m RJ11 cable to any HW group device
- Wall, Ceiling, or Desk Installation – Small and lightweight, can be mounted using adhesive tape
Why Choose Temp HomeBox?
The Temp HomeBox offers simple, reliable temperature monitoring in a compact and easy-to-install design. Whether for home automation, industrial applications, or environmental monitoring, this low-power sensor ensures accurate and consistent temperature readings.
