Description
The Aviosys IP Power 9655 is a versatile single-outlet intelligent power distribution unit (PDU) designed to provide seamless remote management of your critical devices. The outlet supports up to 10A at 100–240VAC, accommodating a wide range of equipment. The unit is equipped with an active surge filter, ensuring reliable operation and protection against power surges.
Featuring an Ethernet RJ-45 port, the 9655 supports multiple network protocols, including HTTP, HTTPS/SSL, IPv4, IPv6, mDNS, SNMP v1 and v2, SMTP, NTP, and Telnet TLS. It also integrates with cloud platforms via MQTT, facilitating advanced IoT applications. For secure communications, Telnet with TLS is supported.
The PDU offers a user-friendly web interface and APIs, allowing control via HTTP commands or MQTT. The auto-ping function monitors device connectivity, performing user-defined actions if a device becomes unresponsive, ensuring continuous operation of your network. The built-in scheduler enables automation of tasks based on a predefined timetable, enhancing operational efficiency.
With support for Wake on LAN, the 9655 allows you to remotely wake up network devices from shutdown, provided they support WOL. Additionally, the unit supports Shutdown on LAN, ensuring proper shutdowns to prevent file system errors. The device includes an ammeter to measure power consumption, aiding in balancing circuits and preventing overloads.
The IP Power 9655 is compact yet powerful, making it an ideal solution for managing and monitoring your essential equipment remotely. Its advanced features and robust design help reduce downtime and save on maintenance costs.
![]() |
HTTP API Command your IPPower through a user-friendly web interface, via curl from the command line, or through your own application using an HTTP GET/POST API (CGI). |
![]() |
MQTT API Control your IPPower through an MQTT bridge using topic-based publish and subscribe methods. |
![]() |
Wake on LAN (WOL) IPPower allows you to remotely wake network devices from shutdown via the Wake on LAN (WOL) service. Enable the WOL service and wake devices using the MAC address list. Ensure that the target device supports WOL before applying this service. |
![]() |
Shutdown on LAN (SOL) Improper shutdowns may lead to file system errors. IPPower includes resident software for PCs, enabling you to remotely shut down network devices via the Shutdown on LAN (SOL) service. You can configure IPPower to perform shutdown actions through the software and, after a delay, turn off the power. |
![]() |
PING The PING function allows monitoring of two IPs with AND/OR logic. If a specified IP does not respond to a ping, IPPower performs a user-defined power action, such as turning an outlet on/off, power cycling, shutting down on LAN, waking on LAN, or sending an email notification. |
![]() |
Scheduled Tasks The task scheduler lets you run predefined actions based on a timetable. Up to 30 schedules can be configured using a web calendar for daily, weekly, or one-time tasks. When triggered, IPPower executes user-defined power actions, such as outlet on/off, power cycling, shutdown on LAN, wake on LAN, or email notifications. |
![]() |
Event Logging All events are logged on the website and sent to a Syslog host server. |
![]() |
Email Notifications SMTP Function: If enabled, IPPower sends email notifications when the device status changes. |
![]() |
Remote Control If the CNT function is enabled, download the Android or iOS app and the Node-RED software package to control and monitor IPPower. |
![]() |
 Ammeter Measure the total amperage drawn by the device. |
